Bridge Erection Cranes

Category: Road And Bridge Crane

Application: Bridge erection cranes are employed to lift the concrete beam or bridge on to the supports of highway construction.

Bridge Erection Crane

Product introduction

Bridge erection cranes mainly consist of the main beam, cantilever beam, under guide beam, front and rear support legs, auxiliary outrigger, hanging beam crane, jib crane and electro-hydraulic system. Applies to three different spans and single-span simply supported beam erection with high operating efficiency.

This type of bridge beam erection cranes can erect straight line, curve line(R is great than 2000m), the longitudinal slope less than or equal to twenty per thousands of 20m,24m,32m, composite beam and continuous steel structure. There is the construction of other working condition. But also provided by simple bracket erection, fixed-point lifting, lifting beam with good stability, high efficiency, safety, and reliability, easy to adjust variable cross and easy to operate.

Erect Bridge Crane mainly designed for highway and railway. According to the situation of present railway with less sub-grade, more bridges and tunnels which connected too closely, Design and manufacture the new box girder bridge girder launcher with double girder. Bridge beam Erection Cranes Mainly used for hoisting (lifting) of concrete girder in bridge construction (bridge building) of general railway and highway.


  • Horizontal operation landing the beam in place at one time;
  • Suitable for the construction of inclined(curved)bridge;
  • Lightweight, convenient and quick transportation, installation and removal;
  • Safe and reliable work, small longitudinal cantilever deflection;
  • The legs are not landed on bridge deck when longitudinal moving, reducing the pressure on the beam/bridge deck.

Technical Detail

Trussed Type Steel Structyre

Trussed Type Steel Structyre


Lifting Mechanism

Lifting Mechanism


Electro Hydraulic System

Electro Hydraulic System


Electric Motor

Electric Motor


Connection Of Steel Structure

Connection Of Steel Structure



Lifting capacity 60 80 100 150
Applied bridge span m 20-30 20-35 30-40 35-50
Applied slope ≤1/20
Rotation radius m 200 250 300 350
Applied tilted angle ° 0~15°
Trolley circulate speed hoisting m/min 1 1.2 0.8 0.6
lengthways moving 6/0.6
horizontal moving 6/0.6
Crane speed lengthways moving 6/0.6
horizontal moving 6/0.6
Carrier-carrying cart moving speed 6/0.6
Total weight t 84 95 146 180
Power supply 3-phase A.C. 50HZ 380V
